Plastic Wood WPC PVC Window Door Frame Profile Panel Making Machine / Production Line

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-65/132
Minimum Order Quantity 1
Price USD 30000~80000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Screw Design Double-screw Screw L/D Ratio 30:1
Condition New Plastic Processed PVC, WPC, Wood-plastic
Application Sheet, Profile Weight 5000 KG
Warranty 1 Year Key Selling Points High Productivity
Applicable Industries Manufacturing Plant Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Screw
Machinery Test Report Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65 Screw Speed (rpm) 2500 Rpm
Voltage According To Requirements Dimension(L*W*H) 20*1.5*3M
Power (kW) 80 Product Name PVC Window Door Frame Profile Panel Making Machine / Production Line
Speed 3 - 10 M/min Cooling Way Water Cooling
Key Words PVC Door Frame Making Machine
High Light

PVC Panel Making Machine


Door Frame Panel Making Machine


Plastic Panel Making Machine

Leave a Message
Product Description

Features of WPC Window Door Profile Board Production Line:
-This production line is widely used to make outdoor or indoor hollow door board, WPC PVC window profile, WPC door frame and so on from PVC and wood powder, The WPC boards has the advantage of water –proof, corrosion resisting, anti-moth, anti-aging, static-free, and flame retarded.
- Easy and convenient for operation and maintain
- Economical price, suitable for large scale investment.
- This production line is used to manufacture WPC profile with different section shape and height.
- The surface of WPC profile can be treated by hot stamping printing, lamination machine,etc. which can make wooden design on surface of WPC board.


Max Door Width
Main Motor Power
150-240 KG/H
300 mm
37 KW
300-350 KG/H
800 mm
75 KW
400-500 KG/H
1200 mm
110 KW
