SJ-90 120 150 PP PE ABS PS PC PMMA Board Sheet Extrusion Production Line

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJ-90 120 150
Minimum Order Quantity 1
Price USD 30000~150000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Single-screw Screw L/D Ratio 35:1
Condition New Plastic Processed PE, PP,PS,ABS
Application Sheet, Plates Weight 30 KG
Warranty 1 Year Key Selling Points Multifunctional
Applicable Industries Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoAlA
Screw Diameter (mm) 150 Mm Screw Speed (rpm) 72 Rpm
Voltage 380V Dimension(L*W*H) According To Model
Power (kW) 180 Screw Model Single Screw
High Light

PMMA Production Line

,

120 PP Production Line

,

PMMA Board Sheet Extrusion Line

Leave a Message
Product Description

PP PE PMMA PC ABS Sheet Board Production Line

Product Description



PP PE ABS PMMA PC Sheet application:

PP PE sheet is widely as envinromentally friendly product which is widely applied in chemical industry,food industry,anti-corrosion industry,home appliance,electronics and packaging as well as other related industries.



PP PE ABS PMMP PC sheet sizes:

Width:1200-3600mm;

Thickness:3-40mm;

Length:customzied.



PP PE PMMA PC PS ABS Sheet Making Machine Description:

1. Special screw design could efficiently increase the plasticization and output up to 800kg/h.

2. Optimized electrical design could achieve automatic control on adjustment and control precisely.

3. Production line adopts Siemens motor,ABB inverter,Schneider contactor and Siemens PLC control system and Siemens touch screen.Reliable electrical components and special designed program could guarantee the machine running smoothly,save power and reduce the waste.



Factory Condition:
Location Indoors
Power Supply No dangerous area
Humidity ≤95%
Temperature 0-40ºC
Power 3-phase, 380V, 50Hz
Total Installed Power 150KVA(Depends on machine model)
Cooling Water ≤25ºC ≥0.3MPa, outdoor water tank: 15-20m3, water circulated with production line
Compressed air 0.3 m³ /min, >0.5MPa,
Equipped with 4-5.5kw air compressor
Production Line Dimension 20m*3m*3.5m
