Pvc Wpc Plastic Wall Panel Machines Wood Plastic Composite Production Line

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-65/132
Minimum Order Quantity 1
Price USD 30000~80000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Double-screw Screw L/D Ratio 132:1
Condition New Plastic Processed PVC
Application Sheet, Profile Weight 1800 KG
Warranty 1 Year Key Selling Points Competitive Price
Applicable Industries Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Other
Condition New Plastic Processed PVC Application Sheet, Profile Showroom Location Philippines, Pakist Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65mm Screw Speed (rpm) 80 Rpm
Voltage 380V 50HZ 3P Dimension(L*W*H) 4235*1520*2450MM
Power (kW) 37 Key Ceiling Board ,sheet
Capacity 150-350kg/h Motor Power 37KW
Output (kg/h) 150 - 350 Screw Type Conical Twin Screw
High Light

Wpc Plastic Wall Panel Machines

,

Pvc Plastic Wall Panel Machines

,

Wood Plastic Composite Production Line

Leave a Message
Product Description

PVC PROFILE EXTRUSION LINE

YF series PVC profile production line suitable to produce PVC profile multi-hole cable duct(4 hole, 6 hole, 7 hole, 9 holeoption), according to different profile section and mold to choose different conical or parallel twin screw extruder and provide relative vacuum sizing tank, haul-off, cutter, stack auxiliary equipment. The capacity of main extruder is from 150kg/h to 450kg/h for option. Special design for haul-off by particular up and down technology of our company, working table stable, reliable and heavy duty force. Vacuum sizing tank having particular big eddy flow cooling system for cooling and sizing easy for cooling and sizing easy for high speed extruding necessary.



Specifications/Items
YF180
YF240
YF300
Max.width of board (mm)
180
240
300
Traction height (mm)
150
150
150
Traction force (KN)
1.8
2
3
Traction speed
0-5
0-5
0-5
Cooling water consume (m³/h)
6
6
6
Compression air (Mpa)
0.6
0.6
0.6
