SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot

Place of Origin Qingdao,Shandong
Brand Name Kechengda
Model Number SRL-Z500/1000
Minimum Order Quantity 1
Price 11000~18000usd
Packaging Details wrapping film
Delivery Time 30 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Vwarranty 1 Year Inveter ABB
Transport Package Container Main Motor Siemens
Key Selling Points Long Service Life Screw Speed Customized
Video Outgoing-inspection Provided
Leave a Message
Product Description

SRL SERIES HIGH-SPEED MIXER

SRL series high-speed mixer is used in mixing, blending, drying, coloring materials in plastic, rubber and chemical industries.SHR series high-speed mixer adopts advanced desgin, it is convenient and safe for operation. It offers small size, light weigth, high effciency, low energy consumption, and low noise.
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 0
SRL-Z SERIES VERTICAL MIXING UNIT

SRL-Z series mixing unit is applicable for mixing, colouring and drying of various resin such as poiyethylene, polypropylene, poiyvinyl chloride etc, and in the process of drying and volatilization of engineering plastic such as ABS polycarbonate etc before forming and processing as well as in the mixing of phenolic resin.
The unit combines heat mixing and cool mixing together,the materials after heat mixing can be goting into cool mixer for cooling automatically, exhaust remaining gasses and avoids agglomerates.

Details Images
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 1
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 2
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 3
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 4
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 5
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 6
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 7
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 8
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 9
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 10
SRL-Z500/1000 Plastic Industry High Speed Mixer Machine PVC Powder Mixing Equipment Cold mixing pot 11
Size Information

Model
Total
Volume(L)
Effective
Volume (L)
Motor
Power (kw)
Paddle
speed (rpm)
Heating
Discharging
SHR-10A
10
7
3
600-3000
self-friction
Manual
SHR-50A
50
30
7/11
750/1500
Electric
Pneumatic
SHR-100A
100
75
14/22
650/1300
Electric
Pneumatic
SHR-200A
200
150
30/42
460/920
Electric
Pneumatic
SHR-300A
300
225
40/55
475/950
Electric
Pneumatic
SHR-500A
500
370
47/67, 55/75, 60/90
430/860
Electric
Pneumatic
SHR-800A
800
500
83/110
370/740
Electric
Pneumatic
SHR-1000A
1000
700
110/150
330/600
Electric
Pneumatic
SHR-1300A
1300
1000
132/200
330/600
Electric
Pneumatic
SRL-Z SERIES VERTICAL MIXING UNIT
Model
Total
Volume
(L)
Effective Volume
(L)
Paddle speed
Motor Power
(kw)
Water
Consumption
Discharging
Weight
SRL-Z100/200
100/200
75/160
650/1300/90
14/22/7.5
3.5t/h
Pneumatic
3T
SRL-Z200/500
200/500
150/320
460/920/90
30/42/11
5t/h
Pneumatic
3.5T
SRL-Z300/600
300/600
200/360
475/950/90
40/55/11
5.8t/h
Pneumatic
3.8T
SRL-Z500/1000A
500/1000
375/650
475/950/90
47/67/15
6.9t/h
Pneumatic
5.8T
SRL-Z800/1600A
800/1600
600/1024
370/740/68
60/90/22
10t/h
Pneumatic
8T
SRL-Z800/2000A
800/2000
600/1500
370/740/68
83/110/22
12t/h
Pneumatic
8.5T
SRL-Z1000/3000A
1000/3000
800/2200
66/68
160/30
15/h
Pneumatic
10T
Model
Overall size
SRL-Z100/200
2500×2000×2200
SRL-Z200/500
4580×2240×2470
SRL-Z300/600
4580×2240×2500
SRL-Z500/1000A
4600×3000×4050
SRL-Z800/1600A
6230×4230×4480
SRL-Z800/2000A
4580×3860×6550
SRL-Z1000/3000A
5800×4500×7300
Packing&Shipping
1.For the loose cargo we will packing by wooden box
2.For the full container loading we are packing the machine by film and some on pallet accordingly
3.We can shipping the goods by air or by sea
4.We will send pictures of cargo loading to our client to check and keep recording
5.We can send cargo to client’s warehouse to loading
