Industrial PE conduit production line Single screw

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJ-65/30
Minimum Order Quantity 1
Price USD 20000~50000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Single-screw Screw L/D Ratio 65/30
Condition New Plastic Processed PE, PP, HDPE, PPR, HDPE/PP, PE/PP, Lldpe, LDPE
Application PIPE Showroom Location Egypt, Viet Nam, Saudi Arabia, Pakistan, India, Mexico, Morocco, Algeria, South Africa, Nigeria, Uzbekistan
Place Of Origin Shandong, China Weight 9000 KG
Warranty 1 Year Key Selling Points Multifunctional
Applicable Industries Manufacturing Plant, Machinery Repair Shops, Construction Works Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Motor, Engine, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoAlA
Screw Diameter (mm) 65mm Screw Speed (rpm) 80 Rpm
Voltage 220V, 380V, 400V, 415V, 440V, 480V Dimension(L*W*H) Pipe Production Line
Power (kW) 37 Pipe Diameter 16-63mm
Extruder SJ65/30
High Light

PE conduit production line

,

PE conduit production line 37kw

Leave a Message
Product Description



PE HDPE LDPE PP-R Pipe Production Line
PE HDPE LDPE PPR Pipe Production Line is designed for producing 16-630mm HDPE/PE sewage pipes/ drainage pipe, water supply pipes, gas supply pipes and for other usage pipes.
Our HDPE/PE pipe production line has feature of high automatic, stable performance, low consumption.
Normal HDPE/PE pipe production line includes: material loader, hopper dryer, SJ series single screw extruder, pipe mould, vacuum calibration tank, spray cooling tank, haul-off, cutter, stacker, winder (for flexible pipes).

Application
1. Industrial liquids transportation pipe.
2. Municipal water supply, water drain, gas supply pipe
3. Urban and rural drinking water pipelines
4. Agricultural irrigation pipe
5. Post and Telecommunications line pipe
6. Electrical Power cable wire protection pipe
7. Industrial liquids transportation pipe
8. Food and chemical industry pipe
9. PP-R Hot & Cold water supply pipe
10. Building heating system pipe, including flooring heating, wall heating and radiating system pipe
11. Central air conditioning system pipe
PRODUCT SPECIFICATIONS
Ф16-63mm PE Pipe Production Line
NO.
Machine Name
Model
Qty.
1.
Auto-loader
ZJ200
1 set
2.
Hopper Dryer
STG-U125, 75 KG
1 set
3.
Single Screw Extruder
SJ65/30, 37 KW
1 set
4.
Co-extruder ( for marking line )
SJ25/25
1 set
5.
PE Pipe Mould
Ф16- 63mm
1 set
6.
Vacuum Calibration Tank
Ф63x6m
1 set
7.
Water Spray Tank
Ф63x6m
1 set
8.
Haul-off Machine
2.2kw
1 set
9.
Double Station Winder
Ф16- 63mm
1 set
Machine model
Model
Pipe Diameter ( mm)
Extruder Model
Capacity ( Kg/hr )
PE 63
Ф16-63
SJ65/30
60-100
PE 110
Ф63-110
SJ90/30
100-150
PE 160
Ф75-160
SJ90/32
150-220
PE 250
Ф110-250
SJ90/33
200-300
PE 315
Ф160-315
SJ100/33
300-350
PE 450
Ф250-450
SJ120/33
500-750
PE 630
Ф315-630
SJ150/33
800-1000
