PVC WPC Door Making Machine Manufacturer Plant PVC Door Panel Production Line

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-92/188
Minimum Order Quantity 1
Price USD 65000~100000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Screw Design Double-screw Screw L/D Ratio 22:1
Condition New Plastic Processed WPC
Application Plates Showroom Location Peru, Saudi Arabia, Indonesia, Chile, UAE, Sri Lanka, Bangladesh
Place Of Origin Shandong, China Weight 20000 KG
Warranty 1 Year Key Selling Points Multifunctional
Applicable Industries Machinery Repair Shops, Food & Beverage Factory, Construction Works , Energy & Mining Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Motor, PLC, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65 Screw Speed (rpm) 39 Rpm
Voltage 380V 50HZ Dimension(L*W*H) 22*2*3m
Power (kW) 100 Material PVC/UPVC+other Material
Screw Style Double Screw Extruder Max Output 250kg/h
Automatic Yes Continuity Produce Yes
High Light

WPC PVC Door Making Machine


Production Line PVC Door Making Machine

Leave a Message
Product Description
Product Description

Discreption of pvc windows and doors profiles line

  1. PVC window and door profile extrusion line also can for making wpc PROFILE
  2. Equipped with specially designed screw, barrel, die-head and auxiliary machines, using advanced processing technique.
  3. The profile is a new environmental friendly product, material mixed plastic, wood and appropriate aditives.
  4. It is widely used for product carrier, packaging box, frame of window & door, decorating board and other outdoor products
  5. Any Profile that you can provide us the drawing we can do it

Parameter of pvc windows and doors profile line

Extruder model SJZ55/110M SJZ65/132M SJZ80/156M SJZ92/188M

Main motor

Power (Kw)

22 37 55 110
Auxiliary Equipment YF240S YF240A YF300A YF600 YF900 YF1200
Production Width (mm) Max240 Max240 Max300 Max600 Max900 Max1200
Vacuum Pump(Kw) 2*5.5 4*5.5 4*5.5 4*5.5





Water Pump(Kw) 1.5 4 4 7.5 7.5 7.5
Hauling Speed 0-5 0-5 0-5 0-3 0-2.5 0-2.5
Auxiliary Equipment Power 22 35 35 44 52 62
Output(kg/h) 70 120 120 180 400
