Cpvc Pvc Pipe Production Line Plastic Pvc Conduit Electric Pipe Making Machine

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-65/132 80/156 92/188
Minimum Order Quantity 1
Price usd 35000~100000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Pipe Material PVC Applicable Industries Manufacturing Plant, Pvc Pipe Making Machine
Video Outgoing-inspection Provided Machinery Test Report Provided
Marketing Type Ordinary Product Warranty Of Core Components 1 Year
Core Components PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump Production Capacity 100-800kg/h
Power 55kw Weight 7000 Kg
Warranty 1 Year Key Selling Points Automatic
Condition New Type Pipe Production Line
Application PVC Water Supply And Drainage Pipe Production Line Voltage 380v Can Customized
Dimension(L*W*H) 35*3*2.5m Input Material Pvc Resin, CaCO3
Factory Voltage 380v 50hz 3phase(customized) Usage Pipe Extrusion
High Light

Cpvc Pvc Pipe Production Line

,

PVC Drainage Pipe Extruder

Leave a Message
Product Description

Cpvc Pvc Pipe Production Line Price Plastic Pvc Conduit Electric Pipe Making Machine Equipment PVC Drainage Pipe Extrusion Line

Application:

It is mainly used in producing various diameters and wall-thickness of PVC pipes for agriculture and constructional plumbing, electrical conduit etc. Can manufacture U-PVC, C-PVC, O-PVC pipe according to customer's requirements

Features
Our PVC pipe extrusion machine has features of low energy consumption, high output, stable running etc.
The standard PVC pipe extrusion machine include: material feeder, SJSZ series conic twin screw
extruder, mould, vacuum calibration tank, spray cooling tank(for big pipe), haul-off, cutter, stacker/automatic belling machine.
Clients also can choose double/four PVC pipe extrusion line to make small size PVC pipes.

The main electrics for PVC pipe extrusion machine adopt Siemens motor, Schneider contactor,ABB inverter, RKC/OMRON temperature controller.
Technical data:
Diameter range
(mm)
Extruder Model
Main motor power
(KW)
Max. Capacity
(KG/H)
Max. Haul off speed
16-40 Dual
SJSZ51/105
18.5 AC
150
10(m/min.)
20-63 Dual
SJSZ65/132
37 AC
250
15(m/min.)
20-63
SJSZ51/105
18.5 AC
120
15(m/min.)
50-160
SJSZ65/132
37 AC
250
8(m/min.)
75-160 Dual
SJSZ80/188
110 AC
450
6(m/min.)
63-200
SJSZ65/132
37 AC
250
3.5(m/min.)
110-315
SJSZ80/156
55 AC
450
3(m/min.)
315-630
SJSZ92/188
110 AC
800
2(m/min.)
