Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork

  • Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
  • Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
  • Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
  • Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
  • Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-80/156
Minimum Order Quantity 1
Price USD 94000~150000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Single-screw Screw L/D Ratio 30:1
Condition New Plastic Processed PP
Application Construction Template,Chinese Standard 8Kg/m2X 14mm Warranty 1 Year
Key Selling Points High Productivity Applicable Industries Manufacturing Plant
Video Outgoing-inspection Provided Warranty Of Core Components 1 Year
Core Components Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw Machinery Test Report Provided
Screw Material 38CrMoALA Screw Diameter (mm) 90
Screw Speed (rpm) 90rpm Voltage 380V Or Customized
Dimension(L*W*H) 10*3.0*2.5 (m) Power (kW) 55
Raw Material Virgin/Recycled PP Or Recycled PP+Fiber Glass Width 1220mm
Thickness Range 12-20mm Reuse Time 60times
Line Speed 1-4m/min After-sales Service Provided Field Installation, Commissioning And Training
Leave a Message
Product Description

PP Hollow Formwork Production Line

Raw feeding----Extrusion----Distribution----Die mold ---- Calibration device----5 roller haul-off unit----Heating oven----2 roller haul-off unit----Cutting unit----Stacker

PVC Building Formwork Production Line

Raw feeding----Extrusion----Die mold ----Calibration device---- Rubber rollers haul-off----Cutting unit----Stacker
Technology Parameters
Item
PP Hollow Formwork Production Line
PVC Building Formwork Production Line
Raw material
Recycled PP
PVC resin+wood powder
Width
915/1220mm
915/1220mm/as customer's request
Thickness
12-18mm
3-30mm
output
600kg/h
450-550kg/h
Appliacation
construction template
furniture,kitchen board and construction template or other wpc product
