Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine

  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
  • Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine
Place of Origin Qingdao，Shandong
Brand Name Kechengda
Model Number SJSZ-65/132
Minimum Order Quantity 1
Price usd 30000~80000
Packaging Details wrapping film
Delivery Time 30 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Temperature Control Omron Final Product Plastic Profile
Condition New Computerized Computerized
Core Components Motor, Gearbox Warranty 1 Year
Material Of Barrel 38CrMoAlA Machinery Test Report Provided
Making Machine WPC Profile Making Machine
Highlight

Stainless Steel Pipe Extrusion Machine

,

Plastic Pipe Extrusion Machine

,

PVC Pipe Extrusion Machine
Leave a Message
Product Description
Products Description

APPLICATION

The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistanceforce in die head extruding channel makes sheet thickness evenly, the internal spiral tank in three rollers ensures an effective cooling and it is easy to change and install net changer with the hydraulic pressure unit, no need to stop machine. The machine extrudes PP/PS granule to PP/PS sheet with single color, which is used for producing plastic products by plastic thermoforming machines, like cups, food container, trays, dishes, bowls, lids, etc.
Data with price
Conic Twin Screw Extruders
Item
35/76
45/100
51/110
55/120
65/132
80/156
80/173
92/188
Output PVC pipe
75
110
150
250
300
450
500
650
900
Main motor kw
7.5
15
18.5
30
37
45
55
75
110
Vacuum pump kw
1.1
1.5
1.5
1.5
2.2
2.2
3
3
4
Barrel option
A: Integral barrel Standard Alloy spraying B: Two parts Bimetallic sleeve C: High filler abrasion resistant
Dossing feeder
Big size of Steep hopper Ensure FIFO No retained material left.
Heator & fans
All heaters are cast Aluminum heaters and energy saving type with soundless cooling blower
Electric case
Standard is Siemens PLC + HYPET soft ware to control whole system
Gear box
Patened gear box with strong torque double circulating cooling system ensure oil low temp.
Weight
1600
2000
2100
2300
3000
3000
4100
4600
8500
Price USD
11500
13500
14500
16300
17500
18500
27500
33000
43500
Screw and Barrel for series Conic Twin Screw Extruder
Items
L/D
Weight /kg
Price /USD
ZS35-A
35/76
200
2000
ZS45-A
45/100
200
2200
ZS51-A
51/110
280
2450
ZS51-B
51/110
280
2900
ZS55-A
55/120
400
2580
ZS55-B
55/120
400
3300
ZS65-A
65/132
480
2850
ZS65-B
65/132
480
3600
ZS65-C
65/132
480
4500
ZS80-A
80/156
750
6300
ZS80-B
80/156
750
7200
ZS80-C
80/156
750
8300
ZS80/173
80/173
840
6950
ZS92-A
92/188
1200
11000
ZS92-B
92/188
1200
14200
Barrel: A: Integral barrel Standard Alloy spraying B: Two parts Bimetallic sleeve C: High Cacium filler abrasion resistant



Stainless Steel Making PVC Pipe Machine / Pipe Extrusion Production Line / Plastic Extruder Machine 0
