plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line

  • plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line
  • plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line
  • plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line
  • plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line
  • plastic conduit pipe production line pvc electrical pipe making machine pvc pipe extrusion line
Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-51/105
Minimum Order Quantity 1
Price USD 25000~40000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Double-screw Screw L/D Ratio 30:1
Condition New Plastic Processed PVC
Application PIPE Weight 6000 KG
Warranty 1 Year Key Selling Points Easy To Operate
Applicable Industries Manufacturing Plant, Other Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Bearing, Motor, Pump, PLC, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65 Screw Speed (rpm) 40 Rpm
Voltage 380v 50hz 3phase (or Customized) Dimension(L*W*H) 25m*1.8m*2.4m
Power (kW) 90 Raw Material PVC,CPVC
Control System PLC(imported Brand) After Warranty Service Video Technical Support
Highlight

pvc pipe extrusion line

,

pvc electrical pipe making machine

,

plastic conduit pipe production line
Leave a Message
Product Description
Machine Description
Mum
Machine
Num
1
PVC Powder Mixing unit
1
2
Screw feeder
1
3
Conical twin screw extruder
1
4
Pipe Mould
1
5
Vacuum Form Water Tank
1
6
Laser Printer (options)
1
7
Hauling Off Machine
1
8
Pipe Cutting Machine
1
9
Stacker (options)
1
10
Pipe Belling Machine(options)
1



Product Paramenters
Model
Pipe range
Max output
Motor power
Dimension(L*W*H)
(mm)
SJSZ 51/105
16-75mm
80-150kg/h
18.5 kw
3360x1290x2127
SJSZ 55/110
32-110mm
150-180kg/h
22 kw
3620x1050x2157
SJSZ 65/132
50-250mm
250-300kg/h
37 kw
3715x1520x2450
SJSZ 80/156
110-315mm
320-400kg/h
55 kw
4750x1550x2460
SJSZ 92/188
315-630mm
600-800kg/h
110kw
6725x1550x2814
