PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder

  • PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder
  • PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder
  • PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder
  • PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder
  • PVC Water Drainage Pipe Extruding Machine PVC Plastic Pipe Extruder
Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJSZ-65/132 80/156 92/188
Minimum Order Quantity 1
Price USD 35000~100000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Double-screw Screw L/D Ratio 22:1
Condition New Plastic Processed PVC
Application PIPE Weight 4500 KG
Warranty 1 Year Key Selling Points High Productivity
Applicable Industries Building Material Shops, Manufacturing Plant, Home Use Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Bearing, Motor, Pump, Gear, PLC, Engine, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65 Screw Speed (rpm) 35 Rpm
Voltage 380V50HZ Customized Dimension(L*W*H) 8900*1550*1150
Power (kW) 37 Raw Material PP PE PVC
Usage Wide Usage Keywords PVC Pipe Extruder Line
Highlight

PVC Water Drainage Pipe Extruder

,

35rpm PVC Plastic Pipe Extruder
Leave a Message
Product Description

PVC Pipe Extruding Machine PVC Water Drainage Pipe Production Line PVC Plastic Pipe Extruder

PVC PIPE PRODUCTION LINE

PVC pipe extrusion line is used to produce pvc pipe with diamater from 16 to 800mm, which are effective,safe
Capacity: Conical twin-screw extruder, suitable for process PVC powder with high capacity
Diameter: We have very successful production experience.Auxiliary machine closely meet customer specifications. Nice
apperance,automatic control and stable running performance.
Model
PVCG-2-50
PVCG-4-25
PVCG-110
PVCG-160
PVCG-250
PVCG-315
PVCG-400
Supporting Extruder
51/105
65/132
51/105
65/132
80/156
80/156
80/156
Pipe Range(mm)
16-50
16-25
20-110
50-160
50-250
110-315
160-400
The length of Vacuum Tank(mm)
4000
4000
6000
6000
6000
6000
6000
Haul-off Speed(m/min)
1.2-12
1-10
0.6-6
0.5-5
0.4-4
0.3-3
0.2-2.5
Installed Capacity(kw)
67
85
67
85
95
125
135
Total Length(mm)
17000
18000
17000
18000
20000
20500
28000
