PE Pipe Extrusion Line 20-110mm Plastic PE HDPE PPR Pipe Making Machine

Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJ-65 75 90 120 150
Minimum Order Quantity 1
Price usd 25000~100000
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Single-screw Screw L/D Ratio 33:1
Condition New Plastic Processed PE, HDPE, PPR
Application PIPE Weight 6 KG
Warranty 1 Year Key Selling Points Competitive Price
Applicable Industries Manufacturing Plant, Machinery Repair Shops, Construction Works Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw, Other
Machinery Test Report Provided Screw Material 38CrMoALA
Screw Diameter (mm) 65 Screw Speed (rpm) 78 Rpm
Voltage 3~380V~50/60HZ Dimension(L*W*H) 3200*1400*2100 Mm
Power (kW) 55 Keywords PE Pipe Extrusion Line
Automatic Grade High Automation Usage Water Pipe
High Light

110mm PPR Pipe Making Machine

,

HDPE Pipe Making Machine 78rpm

Leave a Message
Product Description

PE Pipe Extrusion Line 20-110mm Plastic PE HDPE PPR Pipe Making Machinery/HDPE Production Line/Plastic Extruder

Flow chart of PE pipe extrusion line :

Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder
→ color band extruder → mould and calibrator → vacuum calibration machine → cooling tank→ haul-off machine → cutting machine → stacker(Winding machine)
PE pipe extrusion line application description: This Extrusion Line can be used for different diameter PE Pipe production which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on. So, this pipe production line is a preferred for ductwork system of gas, water pipe and agricultural irrigation pipe between city and village.
Characteristics PE pipe extrusion line : · Capacity: single screw extruder, suitable to process PE resin with high capacity, max 1000kg/h
· Diameter: from 16 to 800mm
· Adopts reasonable design, absorbing safe producing technology, acquiring CE & ISO certificate

Technical Parameter for PE pipe extrusion line :
Pipe Range (mm)
16-63
20-110
75-160
90-250
110-315
160-450
315-630
500-800
Extruder
65/30
65/33
75/30
75/33
90/33
90/33
120/33
150/33
Motor power (KW)
30/37
55/75
75/90
90/110
132
160
280
335
Capacity (Kg/h)
60-130
100-150
200-300
220-350
300-400
350-450
500-600
700-900
Max. Speed
15m/min
10m/min
8m/min
6m/min
3m/min
1.2m/min
1.0m/min
0.8m/min
