plastic extruder 9-50mm PP PE PVC PA Nylon Plastic Single Wall Corrugated Pipe Extrusion Machine line for making electri

  • plastic extruder 9-50mm PP PE PVC PA Nylon Plastic Single Wall Corrugated Pipe Extrusion Machine line for making electri
  • plastic extruder 9-50mm PP PE PVC PA Nylon Plastic Single Wall Corrugated Pipe Extrusion Machine line for making electri
  • plastic extruder 9-50mm PP PE PVC PA Nylon Plastic Single Wall Corrugated Pipe Extrusion Machine line for making electri
  • plastic extruder 9-50mm PP PE PVC PA Nylon Plastic Single Wall Corrugated Pipe Extrusion Machine line for making electri
Place of Origin Qingdao,Shandong,China
Brand Name Kechengda
Model Number SJ
Minimum Order Quantity 1
Price 7000~100000 USD
Packaging Details wrapping film
Delivery Time 35 work days
Payment Terms T/T
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screw Design Single-screw Screw L/D Ratio 25 30 45 50 65 75 80 90 120 150
Condition New Plastic Processed PE, PP, PVC, PA, EVA
Application PIPE Showroom Location Egypt, Canada, Turkey, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kaza
Place Of Origin Shandong, China Weight 8000 Kgs
Warranty 1 Year Key Selling Points High Productivity
Applicable Industries Garment Shops, Building Material Shops, Machinery Repair Shops, Restaurant, Food Shop, Energy & Mining Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw
Machinery Test Report Provided Screw Material 38CrMoAIA
Screw Diameter (mm) 65 Mm Screw Speed (rpm) 100 Rpm
Voltage 380V 50HZ 3Phase(Customized) Dimension(L*W*H) 12m*1m*2m
Leave a Message
Product Description
1,Used condition :
380V/3phase/50HZ
2,Suitable material :
PP, PE , PVC
3,Pipe range :
φ9-50mm
4, output capacity:
60-80kg/h
Production speed
20-30m/min
Extruder model
SJ65
Main motor power
22kw
Machine size
12m*1m*3m(length*width*height)
Detailed Images
Machine list
Quantity
SJ65/30 single screw extruder with auto feeder and drying hopper
1 set
Die head
1 set
Mold: 72 pais of mold blocks
according to customer's requirements
Steel wire unwiding and inserting device
1 set
Forming machine: with water cooling
1 set
Coiling machine, double station
1 set
Electricity control system
1 set
Spare parts
1 set
