Horizontal Servo Controlled Wrapping Machine With 1800rpm Reel Speed Fully Automatic
|
Horizontal Servo Controlled Wrapping Machine With 1800rpm Reel Speed Fully Automatic
| Place of Origin | China |
| Brand Name | Zhongding |
Product Details
Driven Type:
Electricity, Pneumatic
Weight:
100-500KGS
Packaging Accuracy:
0.1% ~ 0.3%
Operation Mode:
Fully Automatic
Working Air Pressure:
0.5-0.75Mpa
Tension Control:
Servo-Controlled
Usage:
Chocolate Twist Package
Marketing Type:
New Product 2020
Material Compatibility:
Copper, Aluminum, Fiber Optic Wires
Highlight:
Wrapping Machine Horizontal
,Wrapping Machine 1800rpm
,Servo Controlled auto wrapping machine
Payment & Shipping Terms
Minimum Order Quantity
1
Price
negotiable
Packaging Details
Different packaging methods are adopted according to different modes of transport.
Payment Terms
L/C, T/T, D/P, D/A
Product Description
Horizontal Servo-Controlled Wrapping Machine with Ultra-Large Tray Storage
The Horizontal Servo-Controlled Wrapping Machine with Ultra-Large Tray Storage is an advanced industrial solution designed for high-speed, precise, and reliable wrapping of wires, cables, and other elongated materials. Equipped with a 1800 rpm reel speed and a servo-controlled tension system, this wrapping machine ensures consistent wrapping quality, minimal material waste, and superior operational efficiency. The ultra-large tray storage can accommodate up to 15000 meters of material, significantly reducing downtime and increasing production throughput.
Applications
This wrapping machine is ideal for cable manufacturing plants, wire processing industries, and other facilities requiring continuous, high-speed wrapping operations. It is suitable for a wide range of materials, including copper, aluminum, and fiber optic wires. Its precision servo control ensures uniform wrapping tension, making it perfect for both single-layer and multi-layer wrapping applications.
Technical Specifications
| Item | Specification |
|---|---|
| Machine Model | ZD-φ400 |
| Tape Reel Specification | φ400 × φ76 × φ100 mm |
| Core Outer Diameter | φ35 mm |
| Reel Speed | 1800 rpm |
| Tray-loaded Storage Volume | 15000 m |
| Industrial Machinery Tractor | 800-1600 kg (optional) |
| Take-up / Pay-off Reel | φ1250-φ1600 |
| Wrapping Drive Motor | 2.2 kW |
| Wrapping Tension | Servo control / Magnetic powder control |
Key Advantages
- High-Speed Operation: Achieves up to 1800 rpm, allowing for maximum productivity.
- Precision Wrapping: Servo-controlled tension ensures consistent material handling and high-quality output.
- Large Storage Capacity: Ultra-large tray accommodates long lengths of material, reducing production interruptions.
- Global Compatibility: Suitable for various types of wires and cables, making it adaptable to multiple industrial standards.
- User-Friendly Design: Intuitive controls and automated operation minimize the need for manual intervention, enhancing safety and efficiency.
Performance Features
- Horizontal structure provides high frame stability with no vibration at high rotation speeds
- Convenient operator access and reduced labor intensity during disk changes
- Large-capacity design enables continuous production of approximately 10,000 meters without stopping
- Mechanical durability designed for 24-hour continuous production
- Frequency conversion control for take-up greatly improves stability and durability
Global Market Deployment
The Horizontal Turret-Type Wrapping Machine provides a reliable, high-efficiency solution for cable, wire, and industrial tape wrapping operations worldwide. Its robust design, intelligent control, and adaptable performance allow manufacturers in Europe, North America, Asia, and emerging markets to standardize wrapping quality, optimize production efficiency, and scale operations globally. This wrapping machine ensures consistent output, reduces operational costs, and supports long-term industrial competitiveness in diverse international markets.
